Presenting our latest kit tailored for G Series S58 powered M cars. In collaboration with industry leaders Precision Turbo and Turbosmart, we are proud to offer what we believe is the most comprehensive kit available. The kit commences with an in-house handcrafted turbo manifold featuring substantial 1.90" OD runners, capable of facilitating over 1500hp flow. Employing Precision Turbo's Next Gen Turbos, engineered for optimal power generation with minimal lag, our Next Gen 6466 ball bearing turbo effortlessly achieves 900whp while maintaining a spool comparable to stock. Turbosmart provides the two 45mm Gen V wastegates included in the kit. We meticulously fabricate 3" charge pipes in close proximity to the engine, ensuring steadfast placement with a welded bracket. Additionally, a heat shield is incorporated to safeguard your fuel line from heat exposure. The kit features a 3.5" stainless downpipe that bifurcates into dual 3" outlets, seamlessly connecting to the factory exhaust. To culminate the system, dual 1 3/4" stainless dump tubes exit to the atmosphere at the rear.
Parts List
- 1.90” OD stainless tubular manifold T4 twin scroll
- PTE Turbo
- 3.5” stainless downpipe (4” for Sportsman turbo)
- 1.75” stainless dump tubes (2)
- (2) Turbosmart 45mm wastegates
- 2 piece 3” charge pipes
- CNC Throttle body adapter flange
- 3” silicone couplers (3)
- 3” t-bolt clamps (6)
- Exhaust v-band clamp
- OEM manifold gaskets (2)
- T4 gasket
- T4 turbo hardware
- Exhaust nuts and bolts
- Donut exhaust gaskets (2)
- Stainless oil drain line assembled 10AN
- CNC Oil Drain Fitting to Block 10AN
- Stainless oil feed line 4AN
- CNC Oil Feed Fitting to Block 4AN
- CNC Oil drain block off flange
- CNC Oil feed block off flange
- Coolant bypass line kit
- CNC PCV block off (catch can kit recommended)
- 1/4” nylon push to connect fittings and line kit
- Heat shield
Optional oil catch can kit using highly engineered Radium Auto Catch Cans. These catch cans are routed in a way to pull vacuum in the crankcase just like the factory system.
